XTA TRUCK AUGER
Built for durability, longevity & capacity
The AGI XTA Series Hydraulic Wheeled Grain Auger is built to deliver unmatched performance, capacity, and convenience for modern farming operations. Engineered with heavy-duty components, high-capacity drive systems, and user-friendly features, the XTA is designed to get the job done faster and last longer—even in the toughest conditions. Whether you need durability for heavy use or easy transport across the yard, the XTA has you covered.
KEY SPECIFICATIONS
MODEL | LENGTHS | CAPACITY (BPH) | TUBING GUAGE | FLIGHTING GUAGE | AGI REBATE |
|---|---|---|---|---|---|
8" XTA | 31’ | 36’ | 41’ | 46’ | 51’ | Up to 3500 BPH | 14 GA | 10 GA | $1000 OFF |
10" XTA | 31’ | 36’ | 41’ | 46’ | 51’ | Up to 5500 BPH | 12 GA | 7 GA | $3000 OFF |
KEY FEATURES
FEATURE | DESCRIPTION |
|---|---|
REVERSING GEARBOX | Reverses auger at all angles with linkage and lockout for easy clean-out. |
ELECTRIC CLUTCH WITH REMOTE | Starts and stops the auger remotely without shutting off the engine; quick and easy to use. |
MAXIMUM BELT STRENGTH | Molded double-banded belts (triple on longer models) ensure strong, slip-free power transfer. |
UPPER DRIVE | Heavy-duty sprockets and lubricated roller chain sized to auger length for durability and longer service life. |
SELF-LEVELING MOTOR | Maintains belt tension at all heights—no manual adjustment needed; reduces slippage and boosts efficiency. |
WEAR EDGE TECHNOLOGY™ | Reinforced flighting edges for longer life at critical wear points. |
OPTIONAL FEATURES
FEATURE | DESCRIPTION |
|---|---|
LED WORKING LIGHTS | Provides enhanced lighting conditions for nighttime operations. |
POLY HOPPERS | Durable and flexible hoppers, minimizing spillage. Available in sizes for 8" and 10" augers. |
STEEL HYDRAULIC LINES | Steel lines with ORB fittings for a cleaner look and reduced risk of leakage (on augers with HD mover). |
POLY FLEX SPOUT | Five-section flex bucket spout that prevents grain spillage and waste, designed for durability. |
ENCLOSED COLLAPSIBLE HOPPER | Easy-to-use, cost-effective hopper that mounts over the intake cage with a removable access door and tow hitch. |
STEEL INTAKE HOPPER | Self-leveling, tapered hopper for smooth grain flow, includes removable access plate and tow hitch. Optional wheel kit available. |
SELF-PROPELLED HEAVY-DUTY MOVER | All-wheel drive, hydraulic steering, and rugged all-terrain tires for tough terrain. Compact design for better hopper access and sharp turning radius. |
